| 起源の場所: | 中国洛陽 |
| ブランド名: | Luoyang Sanwu |
| 証明: | IS09001, IS014001,OHSAS18001 |
| モデル番号: | アルミニウム ワイヤー棒 |
| 最小注文数量: | 20トン |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 輸出標準的な木パレット、顧客の要求に従う巻き枠、または |
| 受渡し時間: | 7-15作業日 |
| 支払条件: | T/T、L/C |
| 供給の能力: | 1ヶ月あたりの9000トン |
| 名前: | アルミニウム ワイヤー棒 | 適用する: | ケーブル と ワイヤ ソリューション |
|---|---|---|---|
| 容量: | 1日あたりの300tons | 直径: | 8.0mm.9.5mm、12mm |
| 使用法: | AAC AAAC ACSR | 処理サービス: | 曲げ、溶接、パンチ、切断 |
| ハイライト: | EC grade aluminum wire rod,1050 aluminum wire for electrical,9.5mm 1060 aluminum wire rod |
||
Engineered for maximum efficiency in high-power applications, our ultra-conductive aluminium wire rods represent the pinnacle of electrical performance. Utilizing specialized purification processes and optimized thermo-mechanical treatment, we achieve exceptional conductivity ratings of 63-64% IACS - among the highest available in commercial aluminium conductors. These rods undergo rigorous quality control including ultrasonic testing and eddy current inspection to ensure perfect internal structure and surface quality for demanding power transmission applications.
Quick Details
Specifications : ASTM B211, AMS 4120, AMS 4339, AMS-QQ-A-225/6, ASTM B221, AMS 4152, AMS 4164, AMS 4165, AMS-QQ-A-200/3
Standard : ASTM, ASME
Surface: Bright, Polish & Black
Aluminium Round Bar: Temper:O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Length :1M-6M,12M & Required Length
Diameter : 6.00 mm to 600.0mm
Grade : 1060,2014,2023,2a12,2024,5154, 5056, 5083, 5086, 5182 5005, 6061,6063,6082,7075,7a04
Product Description
Purity |
Chemical Composition% |
|||||
AL Minimum |
Foreign Content,Maximum |
|||||
Si |
Fe |
Cu |
V+Cr+Mn+Ti |
Other |
||
Al99.60E |
99.6 |
0.08 |
0.20 |
0.005 |
0.01 |
0.3 |
Type |
Tensile Strength,N/mm² | Fracture Toughness%,Min | Electrical Resistance Ωmm²/m 20,Max |
| A | 60-80 | 25 | 0.02755 |
| A2 | 80-110 | 12 | 0.02785 |
| A4 | 95-115 | 10 | 0.02801 |
| A6 | 110-130 | 8 | 0.02801 |
| A8 | 120-150 | 6 | 0.02801 |
Temper |
Tensile Strength |
|
Ks j |
M pa |
|
1350-O |
8.5-14.0 |
59-97 |
1350-H12 and-H22 |
12.0-17.0 |
83-117 |
1350-H14 and-H24 |
15.0-20.0 |
103-138 |
1350-H16 and-H26 |
17.0-22.0 |
117-152 |
Temper |
Resistivity |
Equivalent Volume Conductivity,% |
Max.Ω.mm2/m |
IACS Min. |
|
1350-O |
0.027899 |
61.8 |
1350-H12 and-H22 |
0.028035 |
61.5 |
1350-H14 and-H24 |
0.028080 |
61.4 |
1350-H16 and-H26 |
0.028126 |
61.3 |
Advantages:
Maximum Conductivity: 63-64% IACS rating reduces energy loss in critical applications
Superior Homogeneity: Continuous electromagnetic stirring ensures uniform crystalline structure
Enhanced Purity: 99.8%+ aluminium content with controlled trace elements
Premium Surface Quality: Laser inspection and polishing for defect-free surfaces
Performance Certification: Third-party verified to exceed IEC 62004 requirements
Applications:
Extra-high voltage transmission lines (400kV+)
Critical power infrastructure projects
Nuclear power plant safety systems
Data center backup power systems
Renewable energy integration projects
Packing & Shipping
1.Standard seaworthy export packaging. Wooden pallets with plastics protection for the coil and sheet.
2.The packaging can be eye to sky or eye to wall based on the customer's requirement.
3.26 MT can be located into 20FCL, the sea freight rate is much cheaper than 40FCL.
4.Delivery Time: 15-25 days after receiving 30% Prepayments
Luoyang Sanwu Cable Co., Ltd., with registered capital of 106 million RMB, is a high-tech development company for scientific research, industry production and trading , offering a diverse selection of quality wires and cables to industrial customers in 33 countries worldwide. The leading products are ACSR, overhead conductor, AAAC, AAC, power cable, BLXY, home-used wire and so on.
FAQ
Q1. Are you a manufacturer?
Yes, we are a manufacturer own factory with almost 20 years experiences.
Q2. What are your main products?
Main products including: ACSR, AAC, AAAC ,ACAR,ACSS,ACSS/TW,ACCC,ACSR/AW,ACS ,GSW, Aerial Bundled Cable(Low/Medium Voltage),Power Cable,Copper Alloy Wire for Electrical Railway System
Q3. Which countries and regions have your products been exported to ?
Asia, South America, North America, Europe, Africa, Oceania,including: Peru,Colombia, Chile,Korea, America, Philippines, Vietnam,Singapore, Australia,Dominica,Kenya,Poland,Pakistan,Rwanda,Brazil,Myanmar,Zambia, Congo,Ecuador,Lesotho,Bolivia,Thailand ,Germany,Angola,Yemen,India,Netherlands,Benin,Maldives,Canada,Honduras,Albania,Burundi,Paraguay , Sri Lanka,New Zealand,Bahrain,Costa Rica,Trinidad and Tobago,Guyana, Nicaragua,Mongolia,Haiti,Ghana,Macedonia etc.
Q4. Is the quality of your products guaranteed?
Yes,the quality of our products is highly guaranteed. The products are ISO 9001 ,ISO 14001,OHSAS 18001 certificated. Our workshops are equipped with advanced production and inspection equipment and the products strictly according to international standards or customers' requirements. We do 100% inspection for every batch of semi-finished and finished products.
Q5. What's the package of products ?
The package is usually wooden drums ,steel drums,steel-wooden drums or according to customers' requirement.
Q6. How can I get samples?
Please notify the detailed information of sample you need. If we don't have the exact model, please consider whether the similar model is OK for you. we provide the free samples for inspection while freight is charged.
Q7. What is our payment terms ?
We can accept the following payment terms: T/T, L/C
Upgrade your high-temperature wiring! Download our thermal performance test reports.
